HandiFoam® FR Black (HFO)

Low-Pressure Spray Polyurethane Foam (SPF)
Home » Product Lines » HandiFoam® FR Black (HFO)

HandiFoam® FR Black (HFO) low-pressure, spray polyurethane foam is a chemically cured, two-component system designed specifically for use in a vehicle’s undercarriage, engine compartment and frame. The foam provides a protective layer and helps reduce vibrations, leading to an increase in the longevity of the vehicle and providing a more comfortable operating environment by deadening sound. HandiFoam FR Black (HFO) is black in color which allows the foam to blend in with the vehicle and its components. HandiFoam FR Black (HFO) is available in a variety of disposable and refillable sizes and is dispensed using the patented Handi-Gun® Dispensing Unit.

This product is formulated utilizing an HFO blowing agent which is part of our ongoing commitment to developing foam chemistries with lower global warming impact and enhanced product performance.














R Value

Initial:
6.5 at 1 inch thickness

Density

Free Rise:
1.7 lbs/ft3 (28.0 kg/m3)
In-Place: 2.0 lbs/ft3 (32.0 kg/m3)

Tack-Free Time 30-45 seconds
Cuttable 10 minutes (est.)
Cell Structure > 90% CLOSED cell content
Fire Rating

ASTM E84 Class 1 (A) at 1" thick

Flame Spread: 20

Smoke Developed: 350

Shelf Life

6 months – Refill
12 months – Disposable

Warning

 WARNING: CANCER  - www.p65Warnings.ca.gov

Item Number
Description
Size
Dispensing Type
Yield
P12741

HandiFoam® FR Black (HFO)

II-600
Disposable
601 ft2 (55.8 m2)
P23083

HandiFoam® FR Black (HFO)

8 gallon
Refillable
1,015 ft2 (94.3 m2)
P23223

HandiFoam® FR Black (HFO)

60 gallon
Refillable
7,783 ft2 (723 m2)
P23317

HandiFoam® FR Black (HFO)

120 gallon
Refillable
13,989 ft2 (1,300 m2)

  • Insulation
    • OEM
      • Commercial vehicles
      • Trailers
      • Recreational vehicles
      • Vehicle doors
      • Recreational vehicle sound deadening and underside protection
    • Other
      • Insulating and sealing chicken coops
      • Post installation void filling (ie. hollow stadium seats)
  • Sealants
    • Other


Use our Yield Calculator to determine how much low pressure polyurethane foam you need to complete your next project.

*Yields are based on theoretical calculations, for comparison purposes, and will vary depending on ambient conditions and particular application. Other two-component foam product yields are shown on the specific Technical Data Sheet. These examples are representative of other products of similar size.
